Laminar Flow txee
Qhov Zoo Tshaj Plaws
1, Nruab nrog lub caij nplooj ntoos hlav nce / nqis txav lub qhov rooj nyob rau hauv pem hauv ntej lossis tom qab ntawm lub rooj zaum ua haujlwm (Rau ob sab kev ua haujlwm), hloov tau yooj yim thiab yooj yim los nrhiav, zoo meej huab cua ncig tsim kom tsis txhob muaj pa phem hauv thiab sab nraud.
2, Kev sib cuag hloov kho qhov hluav taws xob kom cua ceev hauv thaj chaw ua haujlwm hauv lub xeev zoo tagnrho txhua lub sijhawm.
3, LED zaub tswj vaj huam sib luag.
4, Lub taub hau pem hauv ntej thiab qhov chaw ua haujlwm yog 304 Stainless Hlau. Ob sab thiab hauv qab yog cov xim zoo nkauj.Or peb tuaj yeem tsim tag nrho lub cev plhaub hauv 304Stainless hlau raws li koj.
5, Kev Xaiv: Hluav Taws Xob Hluav Taws Xob Hluav Taws Xob tuaj yeem teeb tsa raws li koj.
Specifications ntawm Vertical Flow Type
| Index/Model | YJ-CJ-1FD | YJ-CJ-2FD | YJ-CJ-3FD | YJ-HS-880U | YJ-HS-1300U |
Qib ntxuav | Chav Kawm 100 (209E USA) | ||||
Lub rooj ua haujlwm | 870600520 | 1360600520 | 1800625545 | 1030650620 | 1770500600 |
Sab nraud Loj | 10506801600 | 15406801600 | 19207401600 | 13007701800 | 18207451620 |
Ua ntej lim | Polyester Lim | ||||
Main HEPA Lim | 86555538 | 135555538 | 179555538 | 113560038 | 167560038 |
Tus naj npawb ntawm cov kab mob | Tsawg dua lossis sib npaug rau 0.5Cfu/plate.time | ||||
Qhov nruab nrab cua ceev | 0.250.45m/s, ob channels | ||||
Suab nrov | Tsawg dua lossis sib npaug li 60dB | ||||
Fais fab mov | AC, 220V / 50Hz | ||||
Teeb pom kev zoo | Ntau dua lossis sib npaug rau 600Lux | ||||
Ib nrab qhov cua ncov tus nqi | Less than or equal to 0.5μM(XYZ direction) | ||||
Cov ntaub ntawv ua haujlwm | 304 Stainless Hlau, zoo li tsis zoo | ||||
Cov khoom siv phab ntsa sab nrauv | Xim Hlau lossis 304 stainless hlau (Yeem) | ||||
Qhov rai pem hauv ntej | 5 hli toughened iav, tiv thaiv -ultraviolet hluav taws xob, Phau ntawv | Tsis muaj | |||
Hwj chim | 400W | 800W | 800w | 800w | 800w |
Qhov hnyav | 100 kgs | 150 kgs | 250 kgs | 150 kgs | 150 kgs |
Fluorescent teeb / | 20w1/20w1 | 30w1/30w1 | 50w1/50w1 | 30w1/30w1 | 30w1/30w1 |
Kev Ua Haujlwm Sab | Ib Sab | Ib Sab | Ib Sab | Ib Sab | Ib Sab |
Stainless hlau Laminar Flow txee
Peb cov koob no Laminar Flow Cabinets yog siv cov khoom lag luam zoo stainless hlau ua haujlwm thiab cov hlau tsis xeb tawm phab ntsa lossis xim hlau tawm phab ntsa.
Laminar Flow Cabinet tuaj yeem muab koj lub siab huv thiab cov kab mob dawb laminar cua ntws ncig ib puag ncig.Cov cua ntws tuaj yeem yog kab rov tav ntws thiab ntsug laminar ntws.Rau kab rov tav ntws, nws niaj zaus siv rau kev lag luam semiconductor, cov twj siv hluav taws xob thiab lwm yam khoom siv hluav taws xob. laminar ntws yog tsuas yog siv rau microbiology, tshuaj thiab kev tshawb fawb txog kev noj qab haus huv thiab lwm lub koom haum kawm.
Qhov no laminar flow Cabinet yog dav siv los ntawm cov tsev kawm qib siab hauv tsev, tsev kho mob thiab lwm lub koom haum tshawb fawb.
Lub ntsiab nta ntawm Laminar Flow txee
1, Ntshiab lus Askiv tswj qhov system, tshwj xeeb tshaj yog rau cov neeg siv khoom txawv teb chaws.
2, Bactericidal sij hawm tswb muaj nuj nqi thiab nco ua haujlwm ib zaug hluav taws xob tawg.
3, Plaub lub sij hawm tswb tuaj yeem teem caij sib cais los tswj cov txheej txheem sim tau yooj yim.
4, Lub cev tag nrho yog txias-khoov steel.Ntawm cov tshuaj tsuag yas rau txias- dov steel kom muaj zog thiab rigidity ntawm lub moj khaum, txo qhov amplitude thaum khiav.
5, Kev ua haujlwm siab tab sis tsis tshua muaj zog lim tshuab, kev ua haujlwm zoo thiab ruaj khov.
6, Tus tswv cuab ntawm lub rooj ntev zaum txuas nrog elastically, tsis tshua muaj kev vibration thiab suab nrov.
7, Siv cov tshiab tsis yog-ozone- UV teeb, siab zog thiab lub neej ntev.
8, Txais siv hluav taws xob stepless ceev regulator, ntau yooj yim rau kev siv.
9, Cov kiv cua centrifugal yog lub thawv steel, tsis siv hluav taws xob thiab suab nrov, siv sijhawm ntev - yam tsis muaj kev saib xyuas.
10, Lub tswv yim tsim qauv, tsim nyog qauv, yooj yim rau siv thiab tswj.
Peb laminar Flow txee tuaj yeem tsim raws li cov neeg siv khoom.
