Txawb C-arm X-ray Scanner
Peb muab Mobile Digital C-Arm YJX112, peb tau mob siab rau peb tus kheej kom xa koj cov neeg siv khoom siab-Cov khoom siv ua yeeb yaj kiab zoo, kev cob qhia thiab cov lus ntev tom qab- kev muag khoom.
Peb cia siab tias yuav dhau los ua koj lub sijhawm ntev - tus khub lag luam hauv Suav teb.
1.Production ntawm Txawb C Arm YJX112
Orthopedics: osteopathy, diaplasis, nailing
Kev phais: tshem tawm lub cev txawv teb chaws, lub plawv catheter, implanting pacemaker, interventional therapy, ib feem ntawm radiography, yees duab hauv zos, thiab lwm yam haujlwm. Peb mob siab rau peb tus kheej kom xa koj cov neeg siv khoom siab -Cov cuab yeej ua yeeb yaj kiab duab zoo, kev cob qhia thiab cov lus ntev tom qab- kev pabcuam muag, suav nrog feem ntau ntawm Africa thiab Europe Market. Peb cia siab tias yuav koj tus khub ntev nyob hauv Suav teb.
2.Specifications ntawm Mammography Mobile C Arm YJX112
Qeb | Yam khoom | Cov ntsiab lus |
Fluoroscopy / Photography | Siab -Frequency Inverter Power Supply | Cov zis hluav taws xob: 3.5kW |
Automatic Fluoroscopy | Tube Voltage: 40kV-110kV tsis siv neeg hloov | |
Phau ntawv Fluoroscopy | Tube Voltage: 40kV-110kV tsis tu ncua hloov kho | |
Pulsed Fluoroscopy | Tube Voltage: 40kV-110kV tsis tu ncua hloov kho | |
Kev yees duab | 40 kV-110 kV | |
Phaj tuav Size | 200mm250mm(8″10″)or | |
X-ray Tube | X-Ray Tube Tshwj Xeeb rau High Frequency | Tsau anode Dual {{0}} tsom: 0.3 / 1.5mm |
VideoSystem | Duab Intensifier | TOSHIBA 9" image intensifier |
CCD Video koob yees duab | Kev kho mob Mega-pixels digital CCD lub koob yees duab | |
Saib xyuas | 14'' high-definition Medical VGA monitor | |
Chaw Ua Haujlwm Chaw Haujlwm Software | Cia yam tsis muaj kev puas tsuaj, ntau- cov duab tso saib, duab W/L tiag- lub sijhawm hloov pauv, hloov pauv grey, thaj tsam ntawm kev txaus siab tshuav, GAMMA kho, tig, txo suab nrov, ua kom hnyav, smoothing, sharpening, compression, Zoom nyob rau hauv, ntsuas, hais lus, duab-text typeset print, expert template, DICOM image transmit, DICOM image print, cine loop, image imprinting, Worklist register etc. | |
Kev ua tau zoo ntawm cov qauv | Cov lus qhia log | Direction wheel 360 degree rotation, main wheel ±90 degree rotation |
C- caj | Hluav taws xob Ascending Descending ntawm ncej txav: 400mm Qhov siab: 750mm Arc qhov tob: 640mm |
3.Product Nta ntawm Txawb C Arm YJX112
1) Kev tsim qauv tshiab, compact tsos, ua haujlwm yooj yim
2)High-zoo ua ke HF-HV X-ray generator, zoo heev txo cov X-ray irradiation.
3) Hluav taws xob rotatable adjustable collimator
4) Cov tes tshwj xeeb - tuav cov chaw taws teeb tswj, ua haujlwm yooj yim dua
5) Graphical colourful LCD kov npo console interface, ua haujlwm yooj yim, tsim qauv tsim
6) Toshiba duab intensifier yog ua haujlwm, ruaj khov thiab txhim khu kev qha zoo, siab -txhais duab thiab tso saib system
7) Nrog rau qhov kev xav VK, MA tsis siv neeg taug qab feature, cov duab ci ntsa iab thiab txhais tau raug teeb tsa ntawm kev ua haujlwm zoo.
4.Txoj kev tsim kho ntawm Mobile C Arm YJX112
| Tsis muaj. | Yam khoom | Ntau |
1 | Mainframe ntawm C-arm | 1 |
2 | X-ray generator thiab siab zaus inverter fais fab mov | 1 |
3 | Toshiba 9'' image intensifier | 1 |
4 | Kev kho mob Mega-pixels digital CCD lub koob yees duab | 1 |
5 | Digital Acquisition and Processing workstation | 1 |
6 | 19'' LCD monitor | 1 |
7 | 14'' high-definition Medical VGA monitor | 1 |
8 | Imported mini groove daim phiaj | 1 |
9 | Hluav taws xob adjustable collimator | 1 |
10 | Tes tswj | 1 |
11 | Lub teeb liab hla localization | 1 |
5.Kev xa khoom, xa khoom thiab ntim ntawm Txawb C Arm YJX112
YJX112D C Arm X-ray tuaj yeem xa tuaj tsis pub dhau 10 hnub ua haujlwm tom qab peb tau txais koj cov nyiaj them poob haujlwm.
Packing nthuav dav raws li hauv qab no:
250011001480mm,
Qhov hnyav tag nrho: 575kg,
Net Nyhav: 440kg
6.FAQ
Q: Koj puas yuav cob qhia peb cov neeg?
A: YOG.
Q: Koj puas yuav pab peb nruab nws?
A: YOG. Tab sis nws tuaj yeem siv ncaj qha.
Q: Yuav ua li cas txog Warranty?
A:2 year. Free spare parts will be sent to you if it's a quality problem.
7.Cov lus pom zoo: Kev sib piv rau YJX112 Series
| Kev sib piv rau YJX112 Series | |||||
Qauv | YJX112/112B | YJX112C | YJX112D/E | ||
Duab |
|
|
| ||
Nqe | |||||
txheej txheem parameter | Fais fab tso zis | 3.5KW / 5KW TSI | 5 kWm | 3.5KW / 5KW TSI | |
Inverter zaus | 40 kHz | 40 kHz | 40 kHz | ||
radiography | cev voltage | 40-110KV / 40-120KV TSI | 40-120 KV TSI | 40-110KV / 40-120KV TSI | |
cev tam | 20-63 Ma / 20-100 mA | 20-100 mA | 20-63 MA / 20-100 MA | ||
mAs | 1-125mAs / 1-180mAs | 1-180 mAs | 1-125mAs / 1-180mAs | ||
fluoroscopy | Tsis siv neeg | 4 0-120KV 0.3-4mA | 4 0-120KV 0.3-4mA | 4 0-110KV 0.3-4mA | |
phau ntawv | 4 0-120KV 0.3-4mA | 4 0-120KV 0.3-4mA | 4 0-110KV 0.3-4mA | ||
mem tes | 40-120KV 4.1-8mA | 40-120KV 4.1-30mA | 40-110KV 4.1-8mA tso zis | ||
cev parameter | hom anode | tsau | tsau | tsau | |
tsom | 0.3/1.5 | 0.3/1.5 | 0.3/1.5 | ||
anode tshav kub muaj peev xwm | 35KJ（47kHu） | 35KJ（47kHu） | 35KJ（47kHu） | ||
lub cev kub muaj peev xwm | 500kJ（666kHu） | 650kJ（867kHu） | 650kJ（867kHu） | ||
Duab Intensifier | Toshiba 9 nti | Toshiba 9 nti | Toshiba 9 nti | ||
CCD | 470,000 8bitWATEC (Nyiv) 8bit | Mega pixel 12 ntsis WATEC (Japanese) | 470,000 8bitWATEC (Nyiv) 8bit | ||
Saib xyuas | ob teev 19 nti LCD npo | 2 teeb 19inch LCD npo, ib qho 19 nti Kho mob siv grey nplai ib qho zaub ntawm C caj npab ncej | 1 set 14 inch CRT monitor fixed at the C arm frame and can rotate for ±135 degree | ||
Txuj | human graphical touch screen DICOM3.0 workstation mega pixel cross laser txoj hauj lwm | tib neeg graphical kov npo DICOM3.0 chaw ua haujlwm mega pixel, hla laser- txoj haujlwm | Tib neeg graphical kov screen WATEC 470, 000CCD hla laser- txoj hauj lwm | ||
xaiv tau | peb pom | peb pom | peb lub zeem muag; laser txoj hauj lwm | ||
