Nta:
-
7 nti siab daws teeb meem xim kov npo
-
12-ua kom tau txais thiab tso tawm ib txhij
-
ECG Tsis siv neeg ntsuas thiab txhais ua haujlwm
-
Ua kom tiav cov ntxaij lim dej digital, tiv thaiv lub hauv paus drift, AC thiab EMG cuam tshuam
-
Compact thiab lub teeb yuag tsim
-
Txhawb USB flash disk thiab micro SD daim npav kom ntev lub cim xeeb
-
Software upgrade ntawm USB/SD card
-
Built-in rechargeable Li-ion roj teeb
Technology Specification:
| Cov khoom | Specification |
| Coj | Standard 12 coj |
| Tau txais hom | Simultaneous 12 coj mus yuav |
| Kev ntsuas ntau | ± 5mVp |
| Input Circuit Court | ntab; Kev tiv thaiv Circuit Court tiv thaiv cov nyhuv Defibrillator |
| Input Impedance | Ntau dua lossis sib npaug li 50MΩ |
| Input Circuit Court tam sim no | ＜0.05µA |
| Cov ntaub ntawv hom | Automatic: 3CH × 4+1R, 3CH × 4, 3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2; |
| Manual: 3CH, 2CH, 3CH+1R, 2CH+1R; | |
| Rhythm: Txhua yam txhuas xaiv tau | |
| Lim | EMG Lim: 25 Hz / 30 Hz / 40Hz / 75 Hz / 100 Hz / 150Hz |
| DFT Lim: {{0}}.05 Hz / 0.15 Hz | |
| AC lim: 50Hz / 60Hz | |
| CMRR | >100 dB |
| Tus neeg mob xau tam sim no | ＜10µA (220V-240V) |
| Zaus teb | 0.05Hz ~ 150Hz (-3dB) |
| rhiab heev | 2.5mm/mV, 5mm/mV, 10mm/mV, 20mm/mV (yuam kev: ± 5%) |
| Anti-baseline Drift | Tsis siv neeg |
| Lub sij hawm tas li | Ntau dua lossis sib npaug li 3.2s |
| Lub suab nrov | 15µVp-p |
| Daim ntawv ceev | 12.5mm / s, 25mm / s, 50mm / s |
| Kev kaw cia hom | Thermal luam ntawv system |
| Daim ntawv specification | Yob 200mmx20M |
| Kev Nyab Xeeb Txuj | IEC / CF |
| Tus nqi piv txwv | Li qub: 1000sps / channel |
| Fais fab mov | AC: 100 ~ 240V, 50 / 60Hz, 30V ~ 100VA |
| DC: 14.8V / 2200mAh, built-in lithium roj teeb |
