Kev Kho Mob Siab Zaus Hluav Taws Xob
1. Nrog kev ua haujlwm siab nruab nrab electrode hu rau kev soj ntsuam system system yuav sim thiab ntsuas qhov chaw sib cuag tau zoo ntawm electrode thiab derma, yog tias thaj chaw contac pom qis rau qib txaus ntshai, qhov system yuav tsis siv neeg txiav tawm thiab muab lub tswb ceeb toom.
2. Muaj lub cim xeeb muaj nuj nqi, khaws cov ntaub ntawv siv sijhawm kawg.
3. Siab txhais loj LED qhia.
4. Lub tsev tseem ceeb muaj kev saib xyuas tsis siv neeg thiab kev ua haujlwm tsis raug
5. Tsis siv neeg them nyiaj ua haujlwm ruaj khov tso zis hluav taws xob, ua kom depletion rau nws qis tshaj.
6. tuaj yeem txiav hauv qab dej, suav nrog cov organic txiav hauv thaj chaw muaj roj nplua nuj.
| TECHNICAL SPECIFICATIONS REQUESTED ELECTROCAUTERIO | |||||
| KHOOM | FORERMED | ||||
| Qauv | YJ-350C | ||||
| Tshooj 13 | ELECTROCAUTERIO | ntsib | tsis ntsib | ntxiv lus | |
| kom muaj nuj nqis | 1 | ||||
| Main Technical Specification |
1 | Tsev kho mob qib, Nrog CE, ISO lossis FDA daim ntawv pov thawj rau khoom siv kho mob. |
CE ISO | ||
| 2 | Nrog mono-polar txiav thiab coagulation | V | |||
| 3 | Nrog built-in micro-bipolar | V | |||
| 4 | Audible thiab pom lub tswb | V | |||
| 5 | Ua tiav microprocessed | V | |||
| 6 | Digital zaub | V | |||
| 7 | Kev hloov pauv ntim ntawm lub vaj huam sib luag pem hauv ntej | v | |||
| 8 | Tsis-volatile nco ntawm lub hwj chim theem nyob rau hauv txhua hom | V | |||
| 9 | Kev hais kom ua los ntawm phau ntawv cwj mem lossis pedal | V | |||
| 10 | Kev ua haujlwm ib leeg pedal lossis ob chav hais kom ua pedal Tsis siv neeg voltage xaiv |
v | |||
| 11 | Lub hwj chim: 120V +/{2}}%, 60Hz | v | |||
| Duration: 1 xyoo | V | ||||
| 12 | Duration: 1 xyoo | V | |||
| Thawj Xyoo: Thawj Xyoo: Lub quarantee yuav tsum them kev txhawb nqa nrog lub sijhawm luv luv (ntau tshaj 24 teev), suav nrog kev pabcuam tag nrho rau kev tsim khoom tsis xws luag, hloov cov khoom puas qhov chaw, ncua kev tiv thaiv txij nkawm raws li Hoobkas pom zoo thiab mus ntsib thov los ntawm tus neeg siv. |
|||||
| Nyob rau hauv cov ntaub ntawv uas cov cuab yeej raug nres vim xav tau kev kho kom raug, muaj xwm txheej ceev cov khoom siv yuav tsum tau muab kom tsis txhob cuam tshuam kev khiav ntawm kev pabcuam. |
V | ||||
| 13 | Installation thiab commissioning | V | |||
| 14 | Kev cob qhia cov neeg siv thiab cov kws kho mob (hauv lub nroog Comayagua, Honduras), suav nrog cov khoom siv thiab lwm yam ntaub ntawv qhia los ntawm tus bider. |
||||
| 15 | Cov neeg siv phau ntawv (kev ua haujlwm) thiab phau ntawv qhia txuj ci muaj nyob hauv Spanish, hauv lub cev thiab digital cov qauv. |
v | |||
| 16 | suav nrog catalog ntawm cov khoom siv thiab accessories. | V | |||
Technical Specification Technical Parameters:
a) Ambient temp.range: 5 * C-40 degree ;
b) txheeb ze humidity: S80:
c) Atmospheric Pressure Range: {{0}}}0~106.0kpa:
d) Lub zog: 220V22V, 50Hz-1;
e) Ua haujlwm zaus: 330 ~ 460kHz;
f) Rated zog: 1100VA+10%:
g) Hom: CF Fais Fab Kev Siv Lub Zog: Tsawg dua lossis sib npaug rau 1100VA (Txiav txiav 400)
Rau qhov tso zis hom:
a) Txiav: 400W
b) Blend 1: 250W
c) Blend 2: 200W
e) Electro Coag 1: 100W
f) Electro Coag 2: 80W
h) Bipolar Coag; 50W Lub Zog: 220V+22V,50Hz+1Hz
Daim ntawv thov:
Muaj feem xyuam rau kev phais dav dav, phais thoracic, orthopedics, obstetrics thiab gynecology, phais urological, phais hlwb, microsurgery, ENT phais thiab lwm yam.
1. Txiav: Ntshiab txiav, tuaj yeem ua haujlwm yooj yim rau cov organic, cov ntaub so ntswg, kev ntxhib los mos, cov nyhuv yog refine txiav, tsis muaj escharosis ntawm qhov chaw.
2. Blend 1: Cov nyhuv yog txiav nrog me me coagulation;
3. Blend 2: tuaj yeem siv txoj haujlwm no ua ke nrog Endoscope, cov nyhuv yog muab cov coagulation zoo dua thaum txiav; 4. Electro Coag 1: hu ua lub zog electrocoagulation, los yog hu ua deg coagulation, rau ib tug sib sib zog nqus coagulation txheej rau cov organic.
5. Electro Coag 2: Hu ua mos electrocoagulation, lossis hu ua Point coagulation, coagulation sai dua, thaj tsam loj dua. Yuav siv tau qhov no ua ke nrog Endoscope;
6. Bipolar Coag: Hu ua sai Bipolar coagulation, muab coagulation muaj nuj nqi sai ntawm khau raj, uas tuaj yeem tiv thaiv cov organic adhesion.
Kev thauj mus los thiab khaws cia
a) Ambient Temp. Ntau yam: -40 degree ~ 55 degree ;
b) txheeb ze humidity: 395%;
c) Atmospheric siab: 500hpa ~ 1060hpa;
Qhov Loj: 365mm (L) × 330mm (W) × 125mm (H)
Qhov hnyav: NW 6.5 KG, GW 10.5 KG
Ntim qhov loj: 46 × 42 × 30 cm
Standard Configuration
a) Main unit: 1 po b) Ob chav footswith: 1 pc
c) ESU cwj mem: 2 pcs d) Electrode (pov tseg): 2 pcs
e) Bipolar forceps; 1pc f) Bipolar forceps cable: 1pc
g) Electrode cable: 1pc
h) Fais fab cable: 1pc j) Cov neeg siv phau ntawv: 1pa
k) Cov Ntawv Teev Npe: 1 po I) Daim npav lav: 1pc
