Ob Chav Pump Hemodialysis Tshuab
Hemodialysis yog hais txog kev tshem tawm qee qhov pov tseg hauv cov ntshav los ntawm cov khoom siv semipermeable. Hemodialysis yog ib txoj kev nyab xeeb, yooj yim thiab siv dav hauv kev ua kom cov ntshav huv. Dialysis yog hais txog cov kua dej los ntawm daim nyias nyias los ntawm kev daws teeb meem siab mus rau qhov kev taw qhia ntawm qhov tsis tshua muaj siab. Hemodialysis suav nrog kev txav ntawm cov kuab tshuaj thiab kev txav ntawm cov dej, uas yog, hauv lub tshuab lim dej (lub raum cuav), cov ntshav thiab cov tshuaj lim dej tau hloov pauv hauv lub tshuab lim dej (lub raum cuav) los ntawm kev sib cuag ib nrab permeable thiab cov concentration gradient, yog li ntawd, metabolic pov tseg thiab tshaj electrolyte nyob rau hauv cov ntshav yog txav mus rau lub dialysate, thiab cov calcium ion thiab lub hauv paus nyob rau hauv lub dialysate yog tsiv mus rau cov ntshav. Yog tias qhov sib xyaw ntawm albumin thiab urea tau muab tso rau hauv lub tshuab lim dej thiab tsau rau sab nraum lub raj, cov urea hauv lub tshuab lim dej txav mus los ntawm lub raum khoom siv lub qhov rau hauv cov dej sab nraum lub raj, thiab cov albumin molecule loj thiab tsis tuaj yeem hla mus rau hauv lub raum. membrane qhov. Qhov no me me molecules thiab macromolecules tuaj yeem dhau los ntawm cov khoom siv tsis tuaj yeem yog qhov tshwm sim ntawm lub xov tooj hu ua diffusion membrane. Lub hauv paus ntsiab lus ntawm hemodialysis yog cais thiab ntxuav cov ntshav thiab ntxuav nws los ntawm diffusion.
Daim ntawv thov kev kho mob
>Hemodialysis (HD)
>Ntshiab Ultrafiltration (ISO UF)
>Hemoperfusion (HP)
>Hemofiltration (HF)
>Plasma Exchange (PE)
Lub ntsiab technical parameter
Volume (ntev dav qhov siab): 370mm340mm 1570mm
Qhov hnyav: txog 90kg
Power supply voltage: AC220V±10 percent
Zaus: 50HZ 60HZ
Lub zog: 1500W
Ntshav twj tso kua mis / spare pump
Flux: 15 340ml / min (D 6mm)
20 460 ml / min (D 8 hli)
Heparin twj tso kua mis:
Flux: 0.1ml/h10ml/h(±5 percent )
Precise: 0.1ml/h
Injector Loj: 20ml / 30ml / 50ml 10ml / 20ml / 30ml (xaiv tau)
Specifications ntawm Hemodialysis Tshuab YJ-2028M/A
Cov ntaub ntawv dav dav | |
·Dimensions:370x340x1420mm (LxWxH) | |
·Weight:90 Kg | |
·Water inlet pressure:00.6MPa | |
·Water inlet temperature:530 degree | |
·Ambient temperature:1030 degree | |
·Relative Humidity Less than or equal to 70 percent | |
Extracorporeal Circuit Court | |
·Arterial pressure monitoring: | |
Display range: -300 plus 300mmHg (±10mmHg) | |
·Venous pressure monitoring: | |
Display range: -50 plus 300mmHg (±10mmHg) | |
·TMP range: -100 plus 600mmHg (±20mmHg) | |
·Blood pump/ Spare pump: | |
Flow range: 15340mL/min (φ 6mm) 20620mL/min (φ 8mm) | Ntshav ntsuas ntsuas:ultrasonic sensor. |
·Air bubble detector:infrared sensor. | |
Threshold of reaction: single air bubble of 200 µl exists when blood flux is 200mL/min | Heparin twj tso kua mis: |
Delivery range: {{0}}.110mL/hr (±5 percent ) Accuracy: 0.1mL/hr Injector size: 10/20/30mL, 20/30/50mL (optional) | |
Cov ntaub ntawv hluav taws xob |
·Power: 1500W ·Frequency:50/60Hz |
·Voltage:AC220V±10 percent (110V optional) |
Dialysis Fluid Circuit Court |
·Dialysate flow range:linearity adjustable 300800mL / min |
·Dialysate temperature range:Xaiv tau 3539 degree |
·Dialysate conductivity range:1315.5mS/cm (±0.1mS/cm) |
·UF flow range: 04000mL/hr (±30mL/hr) |
·ISO UF flow range: 02000mL/hr (±30mL/hr) |
·Blood leak detector: |
Tsis siv neeg kaw cov hlab ntshav thaum cov ntshav tawm ntau dua lossis sib npaug li 1mL ib liter dialysate (Flow: 500mL / min) |
Disinfection thiab ntxuav |
·Disinfection:Siv citric acid, peracetic acid thiab sodium hypochlorite. |
·Hot rinse temperature:90 degree |
Khoom nta ntawm Hemodialysis Tshuab YJ-2028M/A
LCD touch screen with high definition(10.4") |
Automation: Tus kheej- kuaj, yaug, tshuaj tua kab mob, tshuaj tua kab mob kub, ISO UF, kaw, thiab lwm yam. Tsis siv neeg pib kev kho mob thaum pom ntshav txaus. |
Bicarbonate qhuav hmoov cartridge. |
Siv nrog rau kev lim dej ntawm ntau cov qauv (acetate bicarbonate). |
Ob lub twj tso kua mis: ntshav twj tso kua mis thiab lub twj tso kua mis spare muab ntau txoj kev kho mob; Tau tshaj cov ntshav ntawm cov kab sib txawv. |
Ib Ob rab koob dialysis. |
Siv cov hlau nplaum sib nqus ua hauv Switzerland. |
Hauv - ua roj teeb thaub qab rau max. 30 feeb. |
Dialyzate flux linearity adjustable (300800mL / min). |
Txhawb kev kho mob hauv txaj. |
HCO3 hloov kho rau cov neeg mob hnyav acid toxicosis. |
Hemofiltration therapy ntawm CRRT raum Dialysis khoom:
1. Cov ntshav ntim ntshav siab, mob raum tsis ua haujlwm, mob plawv tsis ua haujlwm
2. tawv tawv siab renin hypertension.Tsis tsuas yog txo cov ntshav ntim tab sis kuj txwv cov ntaub ntawv compression, nrog rau cov txiaj ntsig zoo ntawm kev tswj ntshav siab.
3. Cov laus- cov neeg mob laus, lub plawv tsis ua haujlwm thiab lub siab ua haujlwm tsis zoo.
4. Hypotension thiab dej ntau dhau thiab sodium khaws cia.
5. Cov neeg mob uas muaj cov hlab ntsha thiab pericardium pathological hloov pauv, cov pob txha mob vim yog khaws cia ntawm macromolecule.
Hemodiafiltration kev kho mob:
1. Synthesized qhov zoo ntawm hemodialysis thiab hemofiltraion, uas zoo tshem tawm qhov nruab nrab thiab me me molecular
2. Khoom siv.Nws yog tsim rau cov neeg mob uas muaj creatinin, siab urea nitrogen thiab nrog rau cov tsos mob yuav tsum tau.
3. Kev kho mob hemofiltation, uas ua rau cov neeg mob lim ntshav tau txais txiaj ntsig zoo ntawm cov ntshav huv hauv lub sijhawm luv luv.
CRRT Kev Kho Mob ntawm Dialysis System:
1. Cov kua dej ntau dhau ntawm lub cev thiab tsis siv cov diuretic ARF, mob ntsws pulmonary edema, hydrocephalus Cov kab mob plawv tsis ruaj khov, hypotension, plawv phais laus ARF cov neeg mob thiab tsis tuaj yeem dais HD thiab PD.
2. Tus neeg mob ARF uas yuav tsum tau txais cov khoom noj khoom haus tag nrho hauv cov hlab ntsha hauv siab catabolism.
3. ARF sib koom ua ke ntawm ntau- cov kab mob hauv nruab nrog cev ua haujlwm tsis ua haujlwm
4. Mob ua pa nyuaj-stichen syndrome
5. Tus mob necrotic pancreatitis
6. Extrusion syndrome
7. mob lub siab mob hlwb
8. Multi-organ barrier syndrome
9. Tag nrho lub cev o syndrome
10. Mob qog nqaij hlav dissolution syndrome
